MGBneo⁴

The 660-1100 l wheelie bins MGBneo⁴ are ideally suited for industrial applications and any kind of high-volume waste. The 4-wheel container complies with DIN EN 840 and RAL-GZ 951/1 (GGAWB).

Characteristics:

High manufacturing quality and long lifetime
Strengthened front comb for highest safety during emptying
Steel-reinforced lifting trunnions ensure safe and robust lifting
Handles on all sides of the body
Lid design prevents water ingress when opening the lid

Product enquiry

Art. no.	Outer length (mm)	Outer width (mm)	Outer height (mm)	Volume	Material Lid	Holding Capacity	Available colours
MGBneo4 660 l	1370 ±10 mm	max. 850 mm	max. 1370 mm	660 l	PE	264 kg	grey, green, blue, red, yellow
MGBneo4 770 l	1370 ±10 mm	max. 870 mm	max. 1370 mm	770 l	PE	308 kg	grey, green, blue, red, yellow
MGBneo4 1100 l	1370 ±10 mm	max. 1190 mm	max. 1470 mm	1100 l	PE	440 kg	grey, green, blue, red, yellow

Further links:

Video

Data sheet (PDF)

Art. no.	Outer length (mm)	Outer width (mm)	Outer height (mm)	Volume	Material Lid	Holding Capacity	Available colours
MGBneo4 660 l	1370 ±10 mm	max. 850 mm	max. 1370 mm	660 l	PE	264 kg	grey, green, blue, red, yellow
MGBneo4 770 l	1370 ±10 mm	max. 870 mm	max. 1370 mm	770 l	PE	308 kg	grey, green, blue, red, yellow
MGBneo4 1100 l	1370 ±10 mm	max. 1190 mm	max. 1470 mm	1100 l	PE	440 kg	grey, green, blue, red, yellow

Technical information *¹

Container corresponds to	EN 840, RAL-GZ 951/1
Travelling gear	4 x Ø-200 mm castor wheels, standard equipped with wheel stop
Reciever	Comb lift
Prepared for transponders	Yes
Extra equipment / Accessories ^*2	Automatic lock, Directional lock for castor wheel, Triangular lock, Noise insulation plugs, Glas slot

Art. no.	Outer length (mm)	Outer width (mm)	Outer height (mm)	Volume	Material Lid	Holding Capacity	Available colours
MGBneo4 660 l	1370 ±10 mm	max. 850 mm	max. 1370 mm	660 l	PE	264 kg	grey, green, blue, red, yellow
MGBneo4 770 l	1370 ±10 mm	max. 870 mm	max. 1370 mm	770 l	PE	308 kg	grey, green, blue, red, yellow
MGBneo4 1100 l	1370 ±10 mm	max. 1190 mm	max. 1470 mm	1100 l	PE	440 kg	grey, green, blue, red, yellow

*1:

All specifications quoted are subject to change. Craemer reserve the right to make changes to product design and specification. Dimensions are stated according to DIN EN 840. Variations within the tolerances gives in the norm are possible.

*2:

Extra equipment, accessories, as well as other colors are available at extra cost and on request.

Technical drawings

MGBneo Wheelie Bin 660 l

MGBneo Wheelie Bin 770 l

MGBneo Wheelie Bin 1100 l

Loading quantities (Pcs / Approximate amount)

Container
Truck

Labeling options
On the lid, on the body
Technical drawings

Art. no.: MGBneo4 660 l
Colour:
Runners:
Rim (mm):

Art. no.: MGBneo4 770 l
Colour:
Runners:
Rim (mm):

Art. no.: MGBneo4 1100 l
Colour:
Runners:
Rim (mm):
