Pallet Collar CC2

Palletising and goods handling with half pallets is made simple with the CC2 pallet collar. The half pallet collar folds easily, offers a safe locking mechanism and has integrated handles. It can be used as a single collar and is compatible with both plastic and wooden pallets. In the version without rim, the collar securely interlocks with a pallet lid. The version with 10 mm outside rim also enables direct interlocking with another pallet. These features make the CC2 pallet collar particularly versatile in application. Furthermore, the pallet collar offers a contribution to sustainable logistics as its use helps reduce the use of single-use foil wrapping for goods transportation.

Characteristics:

Safe and easy locking mechanism
Integrated handles
Labelling field for adhesive labels
Transponder bracket
Interlocking
75% volume reduction through folding for space-saving storage and efficient empty runs
Ideal height for loading when using 6 collars and 2 pallets
Increased vehicle fill (double or triple stacking)

Options:

Rim options: without, 10 mm
RFID transponder

Product enquiry

Art. no.	Length x width x height Outer dimensions (mm)	Length x width x height Internal dimensions (mm)	Weight (kg)	Volume	Folding height	Stacking Load* ³	Colour	Rim (mm)	Amount
82560800	814 x 618 x 290 mm	754 x 561 x 290 mm	5.4 kg	122 l	75 mm	400 kg	light grey
82560801	814 x 618 x 290 mm	754 x 561 x 290 mm	5.4 kg	122 l	75 mm	400 kg	light grey	10 mm

Further links:

Data sheet (PDF)

Art. no.	Length x width x height Outer dimensions (mm)	Length x width x height Internal dimensions (mm)	Weight (kg)	Volume	Folding height	Stacking Load* ³	Colour	Rim (mm)
82560800	814 x 618 x 290 mm	754 x 561 x 290 mm	5.4 kg	122 l	75 mm	400 kg	light grey
82560801	814 x 618 x 290 mm	754 x 561 x 290 mm	5.4 kg	122 l	75 mm	400 kg	light grey	10 mm

Technical Data *¹

Internal Dimensions (mm)	814 x 618 x 290 mm
Internal Dimensions (mm)	754 x 561 x 290 mm
Temperature stability	-30 °C to +40 °C, briefly up to +90 °C

Art. no.	Length x width x height Outer dimensions (mm)	Length x width x height Internal dimensions (mm)	Weight (kg)	Volume	Folding height	Stacking Load* ³	Colour	Rim (mm)
82560800	814 x 618 x 290 mm	754 x 561 x 290 mm	5.4 kg	122 l	75 mm	400 kg	light grey
82560801	814 x 618 x 290 mm	754 x 561 x 290 mm	5.4 kg	122 l	75 mm	400 kg	light grey	10 mm

*1:

All technical data include characteristic features, which have been tested under specially defined conditions. Varying data may result from different conditions of usage such as loading method, prevailing temperature and length of storage time. All data and specified information are subject to change without notice. Our service team is pleased to be at your disposal to check the special requirements of your individual application.

*2:

Our service team is pleased to be at your disposal if you require exact information about material compositions.

*3:

Stacking load: With a maximum stacking height of 3 frames and evenly distributed load at approx. 20 °C room temperature.

Technical drawings

CC2

CC1 with rim
Loading quantities (Pcs / Approximate amount)

Guideline: 30-fold stacking on half pallet
Labeling options
Customised printing and numbering available on request depending on quantity. Position upon consultation.
Technical drawings

Art. no.: 82560800
Colour: light grey
Runners:
Rim (mm):

Art. no.: 82560801
Colour: light grey
Runners:
Rim (mm):10 mm
