TC1 Palgrip®

Palgrip^® is a unique anti-slip technology that brings load safety to a new level and it is a Craemer innovation. The TC1 Palgrip^® plastic pallet in Euro format is the solution for any application that requires the uncompromising combination of maximum load safety, extreme stability and high load bearing capacity. The full-surface anti-slip top deck ensures slip resistance even in high humidity conditions or in an inclined position. Its unique grain structure is 100% abrasion-resistant and can be used in any environment thanks to its resistance to heat or cold.

Characteristics:

Available with 3 runners
Perfect for heavy-duty applications
Highest impact and breakage resistance thanks to solid wall thickness throughout and patented welding seam geometry of top and bottom deck
Rackable pallet with great dimensional stability for error-free running on conveyor systems and in automated high-rack warehouses
Optimal for transportation and storage of bagged goods
Hygienic, seamless design for easy cleanability
Chamfered edges on both sides of all runners for optimal handling with forklift trucks
Full-surface Palgrip^® anti-slip top deck

Options:

Steel reinforcement profiles, for a load-bearing capacity of up to 3860 lbs (1750 kg) in high rack
Lid
RFID transponder

Product enquiry

Art. no.	Weight (kg)	Load Capacity (lbs) Static *³	Load capacity (lbs) Dynamic *³	Load Capacity (lbs) In Racking System *³	Color	Runners	ESD	Reinforcement profiles	Central box retainers	Rim	Full-surface Palgrip® anti-slip top deck	Palgrip® anti-slip strips on the top deck	Palgrip® anti-slip pads on the top deck	Palgrip® anti-slip clips on the underside of the deck	Palgrip® anti-slip runners	Anti-slip plugs from the top to the underside of the deck	Amount
87065399	42 lbs	16,550 lbs	2,800 lbs	2,250 lbs	light blue / blue	3, unwelded					●
87065899	42 lbs	16,550 lbs	2,800 lbs	2,250 lbs	grey / blue	3, unwelded					●

Further links:

Data sheet (PDF)

Art. no.	Weight (kg)	Load Capacity (lbs) Static *³	Load capacity (lbs) Dynamic *³	Load Capacity (lbs) In Racking System *³	Color	Runners	ESD	Reinforcement profiles	Central box retainers	Rim	Full-surface Palgrip® anti-slip top deck	Palgrip® anti-slip strips on the top deck	Palgrip® anti-slip pads on the top deck	Palgrip® anti-slip clips on the underside of the deck	Palgrip® anti-slip runners	Anti-slip plugs from the top to the underside of the deck
87065399	42 lbs	16,550 lbs	2,800 lbs	2,250 lbs	light blue / blue	3, unwelded					●
87065899	42 lbs	16,550 lbs	2,800 lbs	2,250 lbs	grey / blue	3, unwelded					●

Art. no.: 87065399
Color: light blue / blue
Runners: 3, unwelded
Full-surface Palgrip® anti-slip top deck: Yes

Art. no.: 87065899
Color: grey / blue
Runners: 3, unwelded
Full-surface Palgrip® anti-slip top deck: Yes

Technical Data *¹

Dimensions	47.2 x 31.5 x 6.3 " (1200 x 800 x 160 mm)
Temperature stability	-22°F to +104°F, briefly up to +194°F

Art. no.	Weight (kg)	Load Capacity (lbs) Static *³	Load capacity (lbs) Dynamic *³	Load Capacity (lbs) In Racking System *³	Color	Runners	ESD	Reinforcement profiles	Central box retainers	Rim	Full-surface Palgrip® anti-slip top deck	Palgrip® anti-slip strips on the top deck	Palgrip® anti-slip pads on the top deck	Palgrip® anti-slip clips on the underside of the deck	Palgrip® anti-slip runners	Anti-slip plugs from the top to the underside of the deck
87065399	42 lbs	16,550 lbs	2,800 lbs	2,250 lbs	light blue / blue	3, unwelded					●
87065899	42 lbs	16,550 lbs	2,800 lbs	2,250 lbs	grey / blue	3, unwelded					●

*1:

All technical data include characteristic features, which have been tested under specially defined conditions. Varying data may result from different conditions of usage such as loading method, prevailing temperature and length of storage time. All data and specified information are subject to change without notice. Our service team is pleased to be at your disposal to check the special requirements of your individual application.

*2:

Our service team is pleased to be at your disposal if you require exact information about material compositions.

*3:

Static load: resistance to pressure on a flat ground surface and an evenly distributed load at a room temperature of approx. 68 °F.

Dynamic load: on a forklift with an evenly distributed load at a room temperature of approx. 68 °F.

In racking system:evenly distributed load (sacks) along the longitudinal sides. Resting on two supports for over 100 h at a room temperature of approx. 68°F.

Technical Data *¹

Art. no.: 87065399
Color: light blue / blue
Runners: 3, unwelded
Full-surface Palgrip® anti-slip top deck: Yes

Art. no.: 87065899
Color: grey / blue
Runners: 3, unwelded
Full-surface Palgrip® anti-slip top deck: Yes
Technical drawings

Loading quantities (Pcs / Approximate amount)

Container	Container 20': 192 St. Container 40': 390 St. Container 40' High Cube: 440 St. Container 45': St. Conventional trailer 45’ high cube container: 495 St.
Truck	MEGA Trailer: 612 St. Jumbo: 684 St.

Labeling options
Customised printing and numbering available on request depending on quantity. Position upon consultation.
