EURO L1®

The standardized wooden pallet in Euro format is known and used across the globe, thus benefitting from worldwide acceptance. Craemer offers the market's first durable plastic alternative that is identical in construction to a wooden Euro pallet and therefore easily interchangeable, running error-free in exclusive or mixed operations with wood. The EURO L1^® Euro plastic pallet is one-piece injection-molded from high-quality PE, extremely durable and remains maintenance-free, even with increased trip rates. The rackable pallet in Euro format is equipped with steel reinforcement profiles for high load bearing capacity. Closed runners ensure smooth running in all automated intralogistics systems, such as conveyor systems or high-bay warehouses.

Characteristics:

Available with 3 runners
Suited for heavy-duty applications
Identical in construction to the standardized wooden Euro pallet
Corrosion-protected reinforcement profiles, for a load-bearing capacity of up to 2800 lbs (1250 kg) in high rack
Rackable pallet
Welded runners offer smooth running on roller conveyors and reliable hygiene
Chamfered edges on both sides of all runners for optimal handling with forklift trucks
Palgrip^® anti-slip strips on the top deck

Options:

Rims: without, 0.3 inch (7 mm)
Lid
RFID transponder
Palgrip^® anti-slip coating under the runners

Product enquiry

Art. no.	Weight (kg)	Load Capacity (lbs) Static *³	Load capacity (lbs) Dynamic *³	Load Capacity (lbs) In Racking System *³	Color	Runners	ESD	Reinforcement profiles	Central box retainers	Rim	Full-surface Palgrip® anti-slip top deck	Palgrip® anti-slip strips on the top deck	Palgrip® anti-slip pads on the top deck	Palgrip® anti-slip clips on the underside of the deck	Palgrip® anti-slip runners	Anti-slip plugs from the top to the underside of the deck	Amount
83241880	44 lbs	16,550 lbs	2,800 lbs	2,800 lbs	light grey / light blue	3, welded		5				●			●

Further links:

Data sheet (PDF)

Art. no.	Weight (kg)	Load Capacity (lbs) Static *³	Load capacity (lbs) Dynamic *³	Load Capacity (lbs) In Racking System *³	Color	Runners	ESD	Reinforcement profiles	Central box retainers	Rim	Full-surface Palgrip® anti-slip top deck	Palgrip® anti-slip strips on the top deck	Palgrip® anti-slip pads on the top deck	Palgrip® anti-slip clips on the underside of the deck	Palgrip® anti-slip runners	Anti-slip plugs from the top to the underside of the deck
83241880	44 lbs	16,550 lbs	2,800 lbs	2,800 lbs	light grey / light blue	3, welded		5				●			●

Art. no.: 83241880
Color: light grey / light blue
Runners: 3, welded
Reinforcement profiles: 5
Palgrip® anti-slip strips on the top deck: Yes
Palgrip® anti-slip runners: Yes

Technical Data *¹

Dimensions	47.2 x 31.5 x 5.9 " (1200 x 800 x 150 mm)
Temperature stability	-22°F to +104°F, briefly up to +194°F

Art. no.	Weight (kg)	Load Capacity (lbs) Static *³	Load capacity (lbs) Dynamic *³	Load Capacity (lbs) In Racking System *³	Color	Runners	ESD	Reinforcement profiles	Central box retainers	Rim	Full-surface Palgrip® anti-slip top deck	Palgrip® anti-slip strips on the top deck	Palgrip® anti-slip pads on the top deck	Palgrip® anti-slip clips on the underside of the deck	Palgrip® anti-slip runners	Anti-slip plugs from the top to the underside of the deck
83241880	44 lbs	16,550 lbs	2,800 lbs	2,800 lbs	light grey / light blue	3, welded		5				●			●

*1:

All technical data include characteristic features, which have been tested under specially defined conditions. Varying data may result from different conditions of usage such as loading method, prevailing temperature and length of storage time. All data and specified information are subject to change without notice. Our service team is pleased to be at your disposal to check the special requirements of your individual application.

*2:

Our service team is pleased to be at your disposal if you require exact information about material compositions.

*3:

Static load: resistance to pressure on a flat ground surface and an evenly distributed load at a room temperature of approx. 68 °F.

Dynamic load: on a forklift with an evenly distributed load at a room temperature of approx. 68 °F.

In racking system: evenly distributed load (sacks) along the longitudinal sides. Resting on two supports for over 100 h at a room temperature of approx. 68°F.

Technical Data *¹

Art. no.: 83241880
Color: light grey / light blue
Runners: 3, welded
Reinforcement profiles: 5
Palgrip® anti-slip strips on the top deck: Yes
Palgrip® anti-slip runners: Yes
Technical drawings

L1

Loading quantities (Pcs / Approximate amount)

Container	Container 20': 215 St. Container 40': St. Container 40' High Cube: 465 St. Conventional trailer 45’ high cube container: 528 St.
Truck	MEGA Trailer: 627 St. Jumbo: 722 St.

Labeling options
Customised printing and numbering available on request depending on quantity. Position upon consultation.
